Kalt Bell_222 (1979 or earlier)

Specification:

 Length  1530 mm / 60 inch
 Height  -
 Main Rotor Dia  1580 mm / 62 inch
 Tail Rotor Dia  -
 Engine  60 cu in  (10 cc)
 Gear  10.5 : 1 : 4.2
 Full Equipped Weight  4.8-5.3 Kg / 10.5-11.5 Lbs
 Autorotation


Documents:








1981 photos and information with Flybarless head option.

Designed for the updated flatbed mechanics utilising collective pitch rotor head and supplied with a fixed tricycle undercarriage with servo operating retracting system as an option.

By 1982 the flatbed mechanics had been upgraded with autorotation and though the catalogue photo's above show a Flybarless head, the basic kit was marketed to include the K-1SB rotor head assembly as noted in the photo's below.


 Autorotation mechanics with K-1SB head assembly 1985 Circus Hobbies (USA) catalogue K-1SB
