Quick Hard Core (2007)
Whilst the OutDo 600 had proved to be a good model and capable of basic 3D, it could not compete with the latest 600 size machines from other manufacturers. To plug the gap a 10S model specifically designed for high performance was introduced with the standard Sport G10 and Pro carbon versions, large battery compartment to suit various battery sizes plus optional tail drive upgrade.
|
Heli features:
|
| |
Adjustable Battery Compartment |
| |
Full Customization Options |
| |
Optional Shaft Drive System |
| |
Optional CNC One-Piece Tail Upgrade |
| |
Stainless Steel Linkage Rods |
|
| |
Compact Design for great 3D performance |
| |
Full Metal Head and Tail (pro version) |
| |
Full Metal Bearing Blocks |
| |
CNC Machined Parts
|
|
For serious high rotor speed 3D flying it was recommended to reduce the blade length to 580mm.
| Specifications |
|
Length
|
49 in with canopy
42.5 in w/o canopy
|
|
Height
|
15.25 in.
|
|
Full Equipped Weight
|
9 lbs (4kg) |
|
Batteries
|
5S x 2 = 10S (42V)
For 8000mah
|
|
Motor
|
Quick Ray Power 4120/ OEM
|
|
Motor KV
|
450 |
|
ESC
|
Phoenix Castle 85 |
|
Blades
|
Quick 600-620-640 mm |
|
Tail Blades
|
85 - 102mm (95mm best suited)
|
|
Frame Thickness
|
2 mm
|
|
Head Speed
|
1650 - 2400* |
|
Pinion
|
10-15 tooth |
|
Spindle
|
8 mm
|
|
Mainshaft
|
10 mm
|
|
Canopy
|
Fiberglass
|
|
Flying
|
Aerobatic to 3D |
|
Flight Time
|
According to MAH |
|
| PRICE CHART |
|
Part Number
|
Heli Type
|
Combo/Kit
|
Price
|
|
|
QKE17S
|
Sport |
Kit Only |
$449.99 |
|
|
QKE17P
|
Sport |
Combo |
$749.99 |
|
|
QKEC17S
|
Pro |
Kit Only |
$549.99 |
|
|
QKEC17P
|
Pro |
Combo |
$899.99 |
|
| Kit Prices are for kit only, Combo includes motor, main blades, ESC, and the kit. |
| Shaft Drive Tail System add $150.00. |
| Differences Between Sport and Pro Kit |
| |
Sport |
Pro |
|
Frames
|
G-10 Fiberglass |
Carbon Fiber |
|
Head
|
Un-anodized w/ plastic blade grips |
Fully Metal Head w/ Thrust Bearings |
|
Boom Supports
|
Fiberglass |
Carbon |
|
Autorotation Hub
|
Yes |
Yes |
|
Warning: No images in specified directory. Please check the directory!
Debug: specified directory - http://www.vrhc.co.uk/images/RC_Helicopters/USA/Quick Worldwide/Hard Core/gal1
The model was to remain until QWW ceased trading.
